HC-2 Oxygen Index Tester

Product Detail

Product Tags

Product Description

HC-2 oxygen index tester is developed according to the technical conditions specified in the national standards GB / t2406.1-2008, GB / t2406.2-2009, GB / T 2406, GB / T 5454, GB / T 10707, ASTM D2863, ISO 4589-2. It is mainly used to test the oxygen concentration (volume percentage) of polymer in the combustion process. The oxygen index of polymer is the volume percent concentration of the lowest oxygen in the mixture of oxygen and nitrogen which can be burned for 50 mm or maintained 3 minutes after ignition.

HC-2 oxygen index tester is simple in structure and easy to operate. It can be used as a means to identify the burning difficulty of polymer, and it can be also used as a related research tool, so as to provide a better understanding of polymer combustion process to people. It is suitable for testing the combustibility of plastics, rubber, fiber and foam materials. It is widely used because of the accuracy and good reproducibility of the samples measured.

Technical Parameter

1.Combustion cylinder inner diameter: 100mm

2.Combustion cylinder height: 450mm

3.Flow meter accuracy: 2.5 level

4.Pressure gauge accuracy: 2.5 level

5.Gas source：Oxygen specified in GB3863, nitrogen specified in GB3864.

6.Test environment: temperature: 10 ~ 35℃, humidity: 45% ~ 75%.

7.Input pressure: 0.2 ~ 0.3Mpa

8.Working pressure: 0.05 ~ 0.15Mpa

Structural Performance

1.The instrument has a reasonable structure and is easy to operate. It consists of a main control box and a combustion cylinder.

2.Using different ratios of nitrogen to oxygen, determine the volume percentage concentration of the lowest oxygen that the polymer maintains combustion.
